Filter manufacturing adhesives
Hot Melt Adhesives for Filter Manufacturing
Air, oil and liquid filters. Hot melts for pleat separation, media-to-metal bonds and end caps: EVA and metallocene when the filter must stay flexible in the cold, polyamide and polyester for heat and chemicals.
Hot melts and water-based adhesives for filter manufacturing and assembly. Air filters, engine and oil filters, liquid and water filters. Bonds films, foams, papers, plastics, fiberglass, nylon, rubber and coated paper. Bead, roll coat, spray or slot die.
Pleat separation
Fast-set hot melt beads hold pleat spacing on high-speed air-filter lines and keep pleats from collapsing under airflow. EVA and metallocene grades stay flexible when the filter sees cold.
Media to metal
Bonding filter media to metal screens, frames and center tubes. Set speed and viscosity are matched to the media and how fast the part moves to the next station.
End caps and frames
Sealing media packs into end caps and frames. Polyamide and polyester (PET) hot melts are used for industrial and automotive filters that see high temperature: chemical and heat resistant, with adhesion to papers and non-wovens.
Cattie grades for filter lines
8521 / 9028: metallocene
| Product number | Chemistry | Viscosity | Set / open time | Heat / cold | Filter use |
|---|---|---|---|---|---|
| 8521 | Metallocene | 700–1,000 cps at 350°F | — | Best in cold; medium heat. Softening point (ring and ball) 228°F | Pleat separation |
| 9028 | Metallocene | ~900 cps at 350°F | Fast set | High heat resistance | Filter lines that need heat resistance; ask us to check the fit |
9029: EVA
| Product number | Chemistry | Viscosity | Set / open time | Heat / cold | Filter use |
|---|---|---|---|---|---|
| 9029 | EVA, freezer grade | Medium viscosity | Fast set | Freezer grade | Pleat separation where the filter sees cold |
9058: polyamide
| Product number | Chemistry | Viscosity | Set / open time | Heat / cold | Filter use |
|---|---|---|---|---|---|
| 9058 | Polyamide | 4,500 cps at 400°F | Fast set | Heat resistance | Automotive air filters; end caps and frames |
Typical values, not specifications. Test for your application. Call 800-249-0337 for the TDS and SDS.
Product numbers are starting points. Ask for the TDS and SDS, and for documentation for your application.
Run tips
Match the open time to the distance between the applicator and the nip or press. Test bonds at the temperature the filter will see in service, and tell us about heat, oil or fuel near the bond line so we can check the grade.
Building filters now? Send us the media and the frame, and we'll quote a grade.
Call 800-249-0337 Request a quote
FAQ
What adhesive is used for pleat separation?
Fast-set hot melt beads hold the pleat spacing on air-filter lines. EVA and metallocene grades are used when the filter must stay flexible in the cold. Tell us the media and the line speed and we will match a grade.
What bonds filter media to metal?
Hot melts with heat resistance are used to bond media to metal frames, screens and end caps. Polyamide grades are used where the filter sees high heat or chemicals. Send us the media and the metal and we will check the fit.
What adhesive is used for filter end caps?
End caps and frames are commonly sealed with hot melt applied by bead or roll coater. Polyamide and polyester hot melts are used for automotive and industrial filters that see heat. Call 800-249-0337 to match the end cap you run now.
Can you match the filter adhesive I run now?
Yes. Send us the grade you run now, the media, the frame or end cap material and your applicator, and we will match it and quote it.
